Float Battery Chargers
Other Products
Product Specifications and Performance
Documentation
SCR Series Document Description
Document Number
Product Brochure
JF5010-00
Operating Manual - Single Phase
JA5009-00
Operating Manual - Three Phase
JA5010-00
Product Specification (PDF)
JF5028-00
Product Specification (DOC)
Standard Product Warranty (PDF)
JF5001-00
Standard Product Warranty
General Terms and Conditions of Sale
DF5001-00
Doc Number
SCR Series Standard Drawings
Instrument Panel Detail (Standard)
JE0260-00
Instrument Panel Detail (options)
JE0260-37
Instrument Panel Detail (options) w/ timer
JE0260-99
Internal Component Layout – NEMA 1 Style 1A Enclosure
JE0240-00
Internal Component Layout – NEMA 1 Style 1B Enclosure
JE0241-00
Internal Component Layout – NEMA 1 Style 2 Enclosure
JE0242-01
Internal Component Layout – NEMA 1 Style 3 Enclosure
JE0243-01
Internal Component Layout (3ph input) – NEMA 1 Style 2 Enclosure
JE0242-03
Internal Component Layout (3ph input) – NEMA 1 Style 3 Enclosure
JE0243-03
Internal Component Layout – NEMA 1 Style 4 Enclosure
JE0244-00
Internal Component Layout – NEMA 1 Style 5 Enclosure
JE0245-00
NEMA 1 Style 1A Enclosure Outline
JE0460-01
NEMA 1 Style 1B Enclosure Outline
JE0461-01
NEMA 1 Style 2 Enclosure Outline (1ph input)
JE0462-01
NEMA 1 Style 2 Enclosure Outline (3 Phase)
JE0462-03
NEMA 1 Style 3 Enclosure Outline (1ph input)
JE0463-01
NEMA 1 Style 3 Enclosure Outline (3ph input)
JE0463-03
NEMA 1 Style 4 Enclosure Outline
JE0464-03
NEMA 1 Style 5 Enclosure Outline
JE0465-03
Mainframe Schematic - 1ph Input
JE5076-00
Mainframe Schematic – 1 phase input w/ CASM (EJ0837) option
JE5077-00
3PH SCR/SCRF Mainframe Schematic
JE5078-00
Mainframe Schematic – 3 phase input w/CASM (EJ0837) option
JE5079-00
NEMA 4/12 Style 1A Closed Enclosure Outline
JE5100-00
NEMA 4/12 Style 1A/1B Wall Mount Enclosure Outline
JE5101-00
NEMA 4/12 Style 2 Floor Mount Enclosure Outline
JE5102-00
NEMA 4/12 Style 3 Enclosure Outline
JE5103-00
NEMA 4/12 Style 4 Vented Enclosure Outline
JE5104-00
NEMA 4/12 Style 5 Vented Enclosure Outline
JE5105-00
1PH Main Control Board Schematic (A1)
EH0573
3PH Main Control Board Schematic (A1)
EH0467-00
1PH Transformer (T1) Schematic
EH0552-00
3PH Transformer (T1) Schematic
EH0553-00
3PH Main Control Board Layout (A1)
GK0048-XX
SCR Series Option Documents
End of Discharge Connection Diagrams
EJ0143-XX
Battery Discharge Ammeter
EJ0138-XX
1PH AC Input Ammeter (Analog)
EJ0134-XX
1PH AC Input Voltmeter (Analog)
EJ0095-XX
3PH AC Input Voltmeter (Analog)
EJ0121-XX
3PH AC Input Ammeter (Analog)
EJ0135-XX
Forced Load Sharing Schematic/Connection Diagram
EJ0133-00
AC Failure Auto-Equalize Timer w/Indicator
EJ0131-XX
Charger Failure Alarm w/Indicator
EJ0127-XX
Common Alarm Relay w/ Optional Buzzer
EJ0141-XX
Battery Discharge Alarm w/Indicator
EJ0120-XX
0-72hr Manual Equalize Timer
EJ0097-01
0-72hr Manual Equalize Timer w/Indicating Lights
EJ0096-01
Float and Equalize Indicating Lights
EJ0093-00
Ground Detect Indicating Lights w/ Test Switch
EJ0089-XX
Ground Detection Indicating Lights
EJ0088-XX
Ground Detect Alarm Relays w/Switch and Indicators
EJ0086-XX
Ground Detect Switches for DC Voltmeter
EJ0094-01
AC Failure Alarm Relay w/Indicator
EJ0085-XX
0-72hr Percent Equalize Timer
EJ0084
High/Low DC Voltage Alarm w/Indicator
EJ0083-XX
High/Low AC Voltage Alarm w/Indicators
EJ0155-XX
Cabinet Heater Strips
EJ0145-XX
Charger OverTemp Alarm w/Buzzer
EJ0439-01
High DC Voltage Charger Shutdown
EJ0592-XX
Combined Alarm Status Monitor (CASM)
EJ0837-XX
CASM for High Voltage Charger
EJ0837-HX
Charger Internal TempCo Network
EJ0826-XX
External Temperature Compensation Probe
EJ1398-XX
0.1% Accuracy Digital DC Meters
EJ0895-XX
1PH SWC Filter Option per IEEE-472
JE0121-00
SWC Filter - 3 Phase Input
JE0126-00
Barrier Type Auxiliary Alarm Contacts
EJ5087-XX
AC Input Lightning Arrestor
EJ1234-XX
1PH Current Limit Alarm w/Indicator
EJ0137-1X
3PH Current Limit Alarm w/Indicator
EJ0137-3X
Remote Alarm (TB3/TB15) Legend
EH0423-00
Miscellaneous Documents and Procedures
Preventative Maintenance Procedure
JD5022-00
Replacing Feedback Voltage Divider
JD0001-00
High/Low DC Voltage Alarm
JD0005-00
High/Low AC Voltage Alarm
JD0063-00
AC Failure Alarm Relay
JD0006-00
Ground Detection Relays
JD0007-00
Charger Failure Relay
JD0010-00
Adding DC Breaker (CB2)
JD0011-00
Manual Equalize Timer
JD0012-00
Changing an Unfiltered SCR charger to a Standard Filtered SCR charger
JD0018-00
Changing a Standard Filtered SCR Charger to Eliminator SCR Charger
JD0020-00
2% Forced Load Sharing
JD0019-00
Ground Detection Indicator Lights
JD0024-00
Adjustments for CASM option
JD0036-00
High DC Voltage Shutdown
JD0037-00
Battery Discharge Alarm
JD0039-00
Float/Equalize Switch w/Lights
JD0040-00
1PH/3PH Main Control Board Replacement
JD0053-00
End of Discharge Alarm
JD0059-00
AC Failure Auto-Equalize Timer Option
JD5004-00
Relocating the CASM PC Board in a Style 1A cabinet
JD5005-00
Dual Chargers with battery discharge alarm/meter
JD0052-00
Clarifying Ripple Specifications
JD5013-00
Theory of Operation of the Combined Alarm Status Monitor (CASM)
JD0017-00
Ground Fault Detection Application Note
JD0062-00
Reducing Positive Feedback in SCR Series chargers
JD5007-00
Adjusting the High-Low DC Voltage PC Board
JD5019-00
Ground Detection in the Real World
JD5032-00
Miscellaneous
Standard Product Warranty (DOC)
